Harrington SEQP003SD-15 Electric Chain Hoist — 1/4 Ton (500 lb), 15 ft Lift, Dual-Speed VFD, 115V — Push Trolley Included

The Harrington SEQP003SD-15 is a 1/4-ton (500 lb) single-phase electric chain hoist with dual-speed VFD control and a 15 ft lift. The SEQP model ships as a complete unit: the electric hoist plus a factory push trolley ready to mount. You are not buying a bare hoist and hunting down a trolley later — the push trolley is included, not optional, and not sold separately on this model.

Built for shops that need precise load placement on single-phase power, with the trolley ready to hang on a compatible I-beam.

Specifications

Shipping / Package

Features

• Factory push trolley included — SEQP means hoist + push trolley as one unit (not optional, not a separate add-on)
• Dual-speed VFD for controlled acceleration and precise placement
• 115/230V single-phase reconnectable motor for flexible shop power
• ASME H4 duty rating for demanding industrial use
• IP55 hoist body and IP65 pendant for dust and water resistance
• Grade 80 Ni-plated load chain with pull-rotor brake
• Push trolley fits 2.28–4.00 in beam flanges
• Low headroom design (C ≈ 16.3 in)

What's Included

• Harrington SEQP003SD-15 electric chain hoist with factory-mounted push trolley
• Chain container
• E-stop pendant control

Applications

Machine shops, fabrication cells, maintenance bays, and light assembly lines that need a 500 lb electric hoist on single-phase power with fine dual-speed control — and a push trolley already on the unit.

Compatibility Notes

• Factory push trolley fits I-beam flanges from 2.28 to 4.00 inches.
• Expect approximately 12.7 A draw at 115V; confirm circuit capacity before install.
• Reconnectable for 115V or 230V single-phase per manufacturer wiring instructions.
